㊣ALPS軸類零組件比較㊣

by alps.tw
2009.05.24 12:40PM
是㊣ALPS軸類零組件比較㊣這篇文章的首圖



㊣ALPS軸類零組件比較㊣新手專用

ALPS軸類零組件比較㊣

基本上以ALPS大腳系(Big foot)相同的鍵帽,之純機械鍵盤來比較,其他ALPS軸不列入

在此僅為大綱分類,以信號簧片(觸發簧片)及彈片(響片)分類,

並不做細部零件差異的分類譬如原生軸的彈片有四種類型,滑片(軸心)(活動部)

近十種顏色(藍軸一代,藍軸二代,橘軸,紫軸,乳白軸等等)】此時全歸為原生軸類。













日本稱呼

概略出現年代

範例鍵盤

ALPS系







BA1

ALPS 原生軸

Big foot

1985~1998

鍵談坊原生軸

BA2

ALPS 原生降音軸



1986

Apple M0115

BA3

ALPS 原生橡膠降音軸



1990

Apple Extended KBⅡM3501





















BB1

ALPS 簡易軸

(簡易Ⅰ)

1995~

福華簡易軸

BB2

ALPS 簡易降音軸



1998

UP94-95





















BU1

ALPS 槽軸



1983~1985

IBM 5578tw































螳螂腳系







T1

回形螳螂腳(大2點)(雙條)

(簡易Ⅱ)

1990~

Mtek_FKD46AK108

T2

回形螳螂腳(小1點)(單條)





FSK-570AS之一, F-21K

T3

回形螳螂腳(小3點)(雙條)





Filco FKB108ZJB

T4

回形螳螂腳(大1點)(單條)



1992

Focus FK-6000

T5

半同形螳螂腳(小1點)(單條)



1990~

Ortek MCK-101FX

T6

小半同形小螳螂腳(GA軸)





LIGWL-101

T7

小閘刀+螳螂腳 (SFON軸)



1994~

鍵談坊經典鍵盤之一

T8

簡易(小1點)(無螳螂腳)







T9

回形螳螂腳(小3點)(三條)



1995























其他系







OA1

回形(大1點)(單條)簡易軸

(簡易Ⅲ)

1991~

Focus FK-2001

OA2

回形(大1點)(單條)簡易軸

(簡易Ⅳ)

1991~

DS-2006 CHN101

OA3

回形(大1點)(單條)簡易(缺口) APC軸





APC F21

OA4

回形(大1點)(雙條)簡易軸





KB-8851































OB1

大閘刀+簡易單鉤(TEC軸)



1989~

Chicony KB-301-5











OB5

大閘刀+簡易單扣(下蓋型)



1992~1993 ?

GL233EKB-5168











OC1

大閘刀+簡易單鉤(KPT軸) 1型



1984~1986

KPT-102

OC2

大閘刀+簡易雙鉤(KPT軸) 2型



1984~1986

KPT-102

OC3

大閘刀+簡易雙鉤(KPT軸) 3型



~1989   ?

































OD1

小閘刀+小簡易單鉤(D-TRNS軸)



1990~

COSTAR CSK-1101S

OD2

小閘刀+簡易軸(ATW軸)



1994~

FKB-102B

OD3

小閘刀+簡易軸((ATW-B型?)





































OE1

小半同形(小1點)(單條)(JL軸)



























OF1

回形簡易(小4點)(三條)(i-Rocks 軸)



2016.05~

i-Rocks K76M











































































下列由圖片來詳端其構造,要分辨為何種軸,自然一目了然



大腳系(Big foot)

BA1=ALPS 原生軸                    鍵談坊原生軸SMK-8104EUH



f666761199295bdc91a53dd01b4deac4



BA2=ALPS 原生降音軸                       Apple M0115



b5934804092ed68068e89c26deae59d3





BA3=ALPS原生橡膠降音軸       Apple Extended Keyboard  M3501



330b2dabcda0637c710f069aee556592





BB1=ALPS 簡易軸                    福華簡易軸



41ae9f63ad3a59cc880e59a9a05903cf



BB2=ALPS 簡易降音               UP94-95



0704001181f9ed2a08366176d839c6e6





BU1= ALPS 槽軸                    IBM 5578tw

此軸應是應該可算是Bigfoot原生軸的第一代軸了,其獨特的長方形凹槽,使得無法安裝彈片,

也因此僅能成為帶燈軸或Bigfoot liner 線性軸。

軸的顏色有.....鮮黃‧米黃‧淺綠‧白‧紫‧灰.....等等....此時全歸類為槽軸。



25b9b26dcdafee78179df4a0ca15f7c2







螳螂腳系

T1=回形螳螂腳(雙條)(大二點) (簡易Ⅱ)      MCK-101FX



cab6516d4dd99d321994e049512bed7a



T2=回形螳螂腳(單條)(小一點)              FSK-570AS



6ac24d195e0f64225343875498254447



T3=回形螳螂腳(3)(雙條)

6a8366fa6ec269142d7dcd64d57db6ec



T4=回形螳螂腳(1)(單條)           FK-6000

T4 T1 兩者之間的差別僅在於回形信號簧片接觸點是單條或雙條而已



c6970c89bef3f1d16db963a3fdc488ef



T5=半同形螳螂腳(1)(單條)

                  Ortek MCK-101FX  (部分斑馬鍵盤)



96b4e3bb455df40ab2856b694a2eb440



T6=(GA) (小半同形小螳螂腳)         LIGWL-101



d5cd8bad9b2858a21c1e56e7b8a0f7db



T7=(SFON)  (小閘刀+螳螂腳)    鍵談坊經典鍵盤EGL-2000XANC (其中一種)



452f948de9c9408dfa339f699c19adc8




T8=簡易(1)(無螳螂腳)



2a8f6c40f144c810c9f03f2678a1367e



T9=回形螳螂腳(3)(三條)…………回形信號簧片分成兩片組合而成(僅靠接觸)



e1bb450ef046945d6323f3cecac5a010














其他系









OA1=回形(大一點)(單條)簡易軸  ~~

回形簡易軸(OA1)跟回形簡易軸(OA2)的差別僅在於

外殼頂部與滑片接觸的地方多了兩條細縫
   (這可能僅是不同批外殼所造成的外觀差異)

然而其他零件是完全相同的,,也就是說手感幾乎無異



fa3423867128d5c7d93b8e3fcb4cf5ae



OA2=回形(大一點)(單條)簡易軸         DS-2006 CHN101



cde8bae5e108166e109f7093ebf994d8



OA3=回形(大一點)(單條)(有缺口)簡易軸     (APC)    APC F21

除了響片那側的外殼多了一個大缺口,有的上蓋有印APC,有的沒有,

並且它的外殼底座兩端是有卡榫的,可很穩固的固定於鐵板。

其餘內部組件幾乎與OA2回形(大一點)(單條)簡易軸幾乎一樣。



ddd51408b21b61042c7a13343fb748b7



OA4=回形(大一點)(雙條)簡易軸

信號簧片接觸點為雙條,彈片的固定腳較前三者長



9310d3ad3d8be54a38c38174a83b952d





OB1=(TEC)  (大閘刀+簡易單鉤)                   Brain  KB-9001S



1e47c61fb75d5ac85506c7373b6dba15



564c68deb7b1f27f4385f13e460d63e1

OB5= (大閘刀+簡易單扣)(下蓋型)

最大的差異在於蓋子在軸的底部,中心滑套並非一般TEC軸的長方形,而是輕微的成井字形               KB-5168

08320dda71919d1a49385e68691ed406



OC1=(KPT) 1  (大閘刀+簡易單鉤)                   KPT-102



dc04455d29cd2e36924278151d6fdd88



OC2=(KPT) 2(大閘刀+簡易雙鉤) ~~~               KPT-102



27639d4a06cc720bac2647c9915b5bad



OC3=(KPT) 3(大閘刀+簡易雙鉤) ~~~



51ccd94bf3706ed2bcbe084de6ae61f0



OD1=(D-TRNS) (小閘刀+小簡易單鉤)      (另有淺黃軸心樣式)        COSTAR CSK-1101S     CTW-060



b87f804087f27323ea1f0c74a1cf4e8b



OD2=(ATW)  (小閘刀+簡易軸)                    FKB-102B



bcf60e437a780056890d895468587fdc



OD3=小閘刀+簡易軸((ATW-B?)..................(此圖由lowe510提供)



d7629dd163b2be5d9f67749c4f2ef1be





OE1=小半同形(1)(單條)JL軸)...........…鍵盤資訊不明..................(此圖由lowe510提供)

目前有淡藍軸與白軸,兩者之間的差別主要在彈簧的強弱

0a5ed727ec957e62f3c7372cd4390324


OF1    回形(小4點)(三條)(i-Rocks 軸)   i-Rocks自有軸,    i-Rocks K76M

                                   2016.05.xx第一批量產青殼軸,茶殼軸,紅殼軸,白殼軸(詭軸)... 除了焊接腳接點位置與

                                   big foot系列相容外與使用跟MX相容十字鍵帽外,其餘各部零組件皆全部全新設計


4770f611be9d303306c50409f51583ab





















而日本人稱為(簡易Ⅰ) (簡易Ⅱ) (簡易Ⅲ) (簡易Ⅳ),,,

僅是近幾年隨意的分為這是第一種, 這是第二種, 這是第三種, 這是第四種,

而已,並不代表軸的出產先後順序,, (簡易Ⅰ)反而是最慢面市的,,



然而台灣正式有簡易軸這個名稱也是因為福華簡易軸的出現,

又受到日本ALPS公司的授權,因稱為ALPS簡易軸。



當然判斷鍵盤是什麼軸,單由鍵盤外表或軸的外表來判斷有些是有難度的

譬如

APC F21相同的外殼型號,至少有2種軸,,就如七彩斑馬Zebra目前已知有2種軸。

Focus FK-2001相同的外殼型號,至少有3種軸。

KB8851相同的外殼型號,至少有5~N種軸。




註:名辭釋疑~~~舉例說明O2=回形(大一點)(單條)簡易軸,,,指的是

回形=回形信號簧片(老一輩有人稱它為蚊香)

大一點=大型信號接片(接點有一個)

單條=回形信號簧片.觸發點僅有一條(一點)

簡易=與簡易軸雷同的彈片(響片)



其他也概略用外型來簡稱之,,,讓人即看即懂,,不需深奧認知



後言: 這一部份僅是概略的分類或許還有一些未發現的軸也說不定隨時補充更新之!



此篇最主要的功用目的只在於讓版友能辨識這是什麼軸而已,並不非常嚴格的講究歷史,

急促成文,錯誤或誤植必不可免,繁請指正

當然其他版友有新發現也歡迎提供補強
